Wi-Fi 6E Series

Arista’s Wi-Fi 6E access points are the building block of a self-driving Wi-Fi network powering AI/ML based continued adaptations, saving time and resources resulting in significant cost savings and increased user and operator satisfaction.

Designed for immediate and future worldwide operation with investment protection, the Arista’s Wi-Fi 6E access points allow dual 5 GHz operation through software configuration where:

• 6 GHz radio operates in the upper 5 GHz band
• 5 GHz radio operates in the lower 5 GHz band.
• When regulations allow or when the 6 GHz clients population justifies, 6 GHz operation can simply be turned on, on all or on selected access points.

With 2x2, 2 stream MIMO and 4x4, 4 stream MIMO on all three access radios, Arista’s Wi-Fi 6E APs future proof your Wi-Fi network with maximum combined peak data rate exceeding 10 Gbps on the high end model. The Multi-functional wall or desktop mounted model also provides wired Ethernet ports for in-room use cases that may require wired devices connectivity and PoE. All models include legendary built-in Arista WIPS to provide the highest security on the wireless and wired network.

Comparisons

Model Number	W-318	C-330	C-360
Description	Indoor tri-band plate AP or desktop stand, optimized for medium density environments with Ethernet/PoE ports to connect wired devices.	Indoor tri-band AP for highest deterministic performance (voice, video, data) for critical, ultra-high networks. Persistent RF analysis by dedicated multifunction radio.	Indoor tri-band AP for highest deterministic performance (voice, video, data), ultra-high density. Persistent RF analysis by dedicated multifunction radio.
Radio Components	802.11b/g/n/ax radio (2.4 GHz)	802.11b/g/n/ax radio (2.4 GHz)	802.11b/g/n/ax radio (2.4 GHz)
	802.11a/n/ac/ax radio (5 GHz)	802.11a/n/ac/ax radio (5 GHz)	802.11a/n/ac/ax radio (5 GHz)
	802.11ax radio (6 GHz)	802.11ax radio (6 GHz)	802.11ax radio (6 GHz)
		802.11a/b/g/n/ac/ax multifunction radio	802.11a/b/g/n/ac/ax multifunction radio
	BLE/ZigBee	BLE/ZigBee	BLE/ZigBee
Antenna	Internal	Internal	Internal
Ports	2 x 2.5Gb Ethernet + 3x 1Gb Ethernet	2 x 2.5Gb Ethernet	2 x 10Gb Ethernet
	Console	Console	Console
	USB	USB 2.0	USB 2.0
Max Data Rate	2.4 /2.4/0.6 Gbps	2.4 /2.4/0.6 Gbps	4.8 /4.8/1.2 Gbps
Spatial Streams	2x2 (2.4GHz); 2x2 (5GHz); 2x2 (6GHz)	2x2 (2.4GHz); 2x2 (5GHz); 2x2 (6GHz)	4x4 (2.4GHz); 4x4 (5GHz); 4x4 (6GHz)
Channel Width	20/40/80/160 MHz	20/40/80/160 MHz	20/40/80/80+80/160 MHz
Power	PoE++ PoE+ (reduced functionality)	PoE+	PoE++ PoE+ (reduced functionality)
	DC Power	DC Power	DC power
Dedicated WIPS	No	Yes	Yes
Mesh Support	Yes	Yes	Yes
LTE Interference Mitigation	Yes	Yes	Yes
WiFi Alliance Certification	Pending	In process	Certified
SKU	AP-W318	AP-C330	AP-C360

All Arista Wi-Fi Access Points support WIPS functionality, either via the multi-function radio or with background scan enabled on the access radios.
